Product Description
Product type: steel workshop buildings
Cost- effective one storey industrial steel buildings for equipment
Our steel buildings are perfect for:
* Steel structure workshops
* Metal warehouse buildings
* Extra storage space or warehouses
* Single or multiple car garages
Why steel house?
- Light-weightness and more resistance to earthquakes and strong winds
- Sustainability and less lifecycle cost thanks to low maintenance costs and highest quality materials
- Shorter construction period with the help of modularity and error-free prefabrication of building elements
- Environment-friendly thanks to reusable steel members and minimized wastes
- Functionality, provided by relocatable, replaceable and load carrying walls and efficient usage of the space
Steel workshop buildings materials component :
| Main Steel Frame | H section steel | Q345 steel 8mm/10mm |
| Welding | Automatic submerged arc welding | |
| Rust removal | Sand blasting | |
| Surface processing | Alkyd paint or galvanized | |
| Intensive bolt | Grade 10.9 | |
| Supporting System | Angle brace | L50x4,Steel Q235, processed and painted |
| Cross support | Φ20, Steel Q235, processed and painted | |
| Belt bar | Φ89*3, Steel Q235, processed and painted | |
| Small brace | Φ12,Steel Q235, processed and painted | |
| Ordinary bolt | Galvanized bolt | |
| Roof | Purlin | C160*60*2.5,Steel Q235, galvanized and painted |
| Outer-roof panel | Sandwich panel or corrugated steel plate | |
| Sky light | 6mm thick PVC | |
| Accessories | Glass cement, self-tapping screws, etc. | |
| Edge cover | Made from 0.5mm thick, colored sheet steel | |
| Gutter | Made from 0.8mm thick sheet steel | |
| Rainspout | Φ110PVC | |
| Walls | Purlin | C160*60*2.5,Steel Q235, painted |
| Wall | sandwich panel or corrugated steel plate | |
| Accessories | Glass cement, self-tapping screws, etc. | |
| Edge cover | Made from 0.5mm thick, colored sheet steel | |
| Ventilation equipment | Ventilation ball | |
| Doors & windows | Rolling door/sliding door PVC/alu/steel window |
Steel structure installation details:
Our services
1. Project Services
Simple or complex,our specical project services team quickly an expertly handle your project.
2. Private manufacturing services(OEM)
We can manufacture and deliver high quality metal building system under your brand name.
Private Label Services.
3.Private Label Services
Promote your company name and brand as a top resource for cost-effective, quality metal buildings.
Steel structure installtion tools:
Electric impact drill, angle grinder, sawing machine, hammer, rivet gun, glass glue gun, tape measure,
cross head screw-driver, adjustable wrench, double ring spanner, ladder, ac welder, crane ect.
Our steel structure processing workshop :
We can use 40HQ shipping container to load even very big steel structure frame:
Steel Buildings for Sale at the Best Prices,just choosing the Right Building for You~
