Product Details:
|
| Color: | Up To Customers' Requirement | Door: | Steel Door |
|---|---|---|---|
| Windows: | Aluminum Sliding Window+Security Mesh | Roof & Wall: | 50mm EPS Sandwich Panel |
| Dimension: | 5850mm*2880mm*2870mm(H) | Key Word: | Sandwich Panel Container House |
| High Light: | prefab shipping container homes,prefab sandwich panel house |
||
Product type: Prefabricated Container House
Custom Fast Assemble Prefab House Container House Sandwich Panel
Product Description
We are manufacturing two types of container houses.
1) Sandwich panel container house.
Less cost,easy transport, fast installation.
2) Shipping container house.
Stronger, fully finish in our factory, wholly pack for export.
Container house is a kind of new prefab house that is different from the traditional products, with the features of more comfortable and convenient. It is mainly used for the large oil field base, building site, market, and wind power station to meet the needs of the constructors’ office and accommodation.
It can be build up as just one container or combining several containers to make different functions.
Materials component
| Material | specification(mm) |
| Column | 155*155*2870*3.0 |
| Bottom beam | 155*90*5662*2.5 |
| Bottom beam | 155*90*2700*2.5 |
| Top beam | 155*90*5662*2.5 |
| Top beam | 155*90*2720*2.5 |
| Corner fitting | 135*100*5.0 |
| Top corner board | 150*150*3.0 |
| Top Platen groove | 2690*0.426 |
| Top Platen groove | 2855*0.426 |
| Bottom floor purlin | 80*40*2700*1.5mm |
| Top roof purlin | 60*40*2700*1.5mm |
| Floor(Mgo Board) | 2746*1142*18mm |
| Roof panel | 5750*950*50 |
| Tile cap | 5760 |
| Door inside the wall (door size:1945*815) | 2538*950*50 |
| window inside the wall (single glass window:1200*925) | 2538*950*50 |
| Wall panel | 2538*950*50*0.286 |
| Front wall panel | 2538*930*50*0.286 |
| Fouling plate | |
| Glass glue(white) | |
| Fixed buckle | |
| Plate groove fixed item | |
| Water outlet | |
| Elbow water outlet | |
| door rock | |
| Window trimming | |
| Main frame bolt | M14*25 |
| Fouling plate screw | M5*25 |
| screw for floor | 4.2*38 |
| Plate groove fixing nail | 4.2*16 |
| screw for roof panel | M5*100 |
| Aluminum rivet | 5*10 |
Materials disply
Production Characteristic
1. Strong construction,energy efficient,reduces construction time,cost saving,technology building,environmental friendly.
2.Time-saving---TPA prefabricates every part of each house within the controlled environment of our factory, which greatly reduces the construction time consumed on site.
3. Cost Reduction---Unlike tradtional house builders,our prefabs technology significantly reduces the on-site workload, saving labor and cost.
4. Anti-earthquake Structure---It is a mature system named light gauge steel structure housing system. Our premium quality structural steel frames and building materials are selected to maximize safety and durability of each house.
5. Fresh Air Inside---We design our homes to maximize airflow and natural energy to keep spaces clean, bright and comfortable.
6. Water proof--we have a special treament for the waterproof
Factory show
Foshan TianPuAn Building Materials Technology Co.,Ltd.(TPA housing),was is founded in 2008. Since then, we have been a professional manufacturer of steel structure building,container house,prefabricated house, railings, light steel villa, sandwich panel and profiled steel with ISO9001&SGS certification. We have two production workshop(Lishui town/Gaoming town)with total area covered 20,000square meter plant and equipped an automatic spraying line and automatic welding machine.
We focus on producing custom-made economic and environmentally friendly prefab house. With the specialized techonology, professional design team and high-quality construction team we undertaken hundreds of prefab buildings production and installation, got the consistent high praise of the clients.
We'd love to give fully support for your further inquiry!
