One story steel structure warehouse for prefabricated hall building
Product Description
Product type: steel structure warehouse
A prefabricated steel structure building is a building that is manufactured and constructed using prefabrication. It consists of factory-made components or units that are transported and assembled on-site to form the complete building.
Materials list
| Items | Specification | |
| Main Steel Frame | Column | Q235, Q355 Welded H Section Steel,galvanized or painted |
| Beam | Q235, Q355 Welded H Section Steel,galvanized or painted | |
| Secondary Frame | Purlin | Q235 C and Z purlin,galvanized |
| Knee brace | Q235 Angle Steel,galvanized | |
| Tie Rod | Q235 Circular Steel Pipe,galvanized | |
| Brace | Q235 Round Bar,galvanized | |
| Vertical and Horizontal Support | Q235 Angle Steel, Round Bar or Steel Pipe,galvanized | |
| Maintenance system | Roof Panel | EPS /Glass Fiber / Rock Wool / Pu Sandwich Panel /Steel Sheet |
| Wall Panel | Sandwich Panel / Steel Sheet | |
| Accessories | Window | Aluminiumn Alloy / PVC Window |
| Door | Sliding Sandwich Panel Door / Rolling Metal Door / Personal Door | |
| Rainspout | PVC | |
| Wind Resistance Grade | 12 Grades | |
| Earthquake-resistance | 8 Grades | |
| Structure Usage | Up to 50 years | |
| Temperature | Suitable temperature.-50°C~+50°C | |
| Certification | SGS,ISO9001:2008,ISO14001:2004 | |
| Paint Options | Alkyd paiting, two primary painting, two finish painting (gray paint, red paint, white paint, epoxy zinc etc.) Or Galvanized. |
|
Steel structure warehouse building characteristic
1. Large span (6-42 m arbitrarily chosen) without beam purlin, support mid-column. spacious internal clearance is admirable.
2. Cost effective, economical and practical, roof insulation, heat insulation, ventilation and lighting system.
3. Easy transportation and fast installation at site,water save, no construction waste.
4. Flexible design, wall and roof materials are available, you can open a window or set us the partiontion in where you want.
5. Light weight, long service life,the main steel frame can be last more than 50 years.
6. Anti-earthquake and waterproof.
