Large Span Multi Story Light Steel Structure Building Steel Structure Construction
  • Large Span Multi Story Light Steel Structure Building Steel Structure Construction
  • Large Span Multi Story Light Steel Structure Building Steel Structure Construction
  • Large Span Multi Story Light Steel Structure Building Steel Structure Construction

Large Span Multi Story Light Steel Structure Building Steel Structure Construction

Place of Origin Guangdong Foshan Lishui, China
Brand Name TPA Housing
Certification ISO, SGS,BV
Model Number TPA-LSB89
Product Details
Material:
Q235 Q355 Low Carbon Steel
Type:
Light Steel Structure Frame
Wall Color:
Grey,white
Life Span:
Steel Frame About 50 Years
Structural Steel Fabrication:
Painting/galvanizing
Wall Panel:
EPS/rock Wool/PU Sandwich Panel, Single Steel Sheet,
Drawing Design:
AutoCAD
Installation:
Installation Drawing Or Engineers Guidance
Application Fields:
Steel Structural Fabrication Construction,Building,workshop Plant/warehouse/hangar,plant
High Light:

Multi Story Light Steel Structure Building

,

Q355 Light Steel Structure Building

Payment & Shipping Terms
Minimum Order Quantity
50 square meters
Price
Negotiable
Packaging Details
In bulk
Delivery Time
5-8 work days
Payment Terms
T/T, L/C at sight
Supply Ability
100000 square meters per month
Product Description

Large Span Multi-Story Light Steel Structure Building Steel Structure Construction



1. Steel warehouse building material parameter



Anchor bolt M20
High streng bolt M20, 10.9s
Shear nail M16
Common bolt M20
Brace M12
Tie rod Ø12
Column(Q345B) Square tube250*250*10*10 Square tube250*250*5*5
Roof beam(Q345B) HN340X250X9X14
Roof frame beam(Q345B) HN294X200X8X12
Floor main beam(Q345B) HN294X200X8X12
Floor secondary beam(Q345B) HN244X175X7X11
Staircases(Q235B) H200X200X6X8+5mm chequered plate
Stair beam(Q235B) H300X200X6X8
Roof purlin C140X60X20X3.0
Connecting plate 3~8mm
Roof tile 75mm rock wool,color sheet both sides 0.426mm
Wall panel 75mm rock wool,color sheet both sides 0.426mm
Floor deck

1.0mm

Steel door

900*2100

Aluminum windows 2000*1500
Zinc steel handrails Square tube80X40+40+30+20
Trimming 1.0mm galvanized sheet, color steel sheet





2. About steel warehouse buildings

Large Span Multi Story Light Steel Structure Building Steel Structure Construction 0

Whether you’re expanding your current business or starting a new venture in the industrial sector, a metal or steel building from TPA Housing steel structure building is your solution. At the core of our success is a team of dedicated, skilled engineers who will provide you with a high quality product. They will take the time to help you design and achieve your vision. Industrial buildings such as warehouses, welding shops and heavy equipment storage facilities require durability and that’s exactly what you get when you purchase one of our steel buildings. No building is too large and no requirement is too complex.





3. Structural steel buildings



Structural steel framing is an option for low-rise, mid-rise, and high-rise building projects. It typically refers to building frame systems where the vertical and horizontal structural elements are formed by a system of structural steel beams and columns.





4. Basic Design Requirements: design Load: (very important)



1. Snow load:

2. Wind load:
3. Seismic magnitude:

4. Middle Column allowed or not:
5. Project location:
6. Length (sidewall, m):
7. Width (end wall, m):
8. Wall Height (eave, m):
9. Mezzanine or not? And usage:



5. A steel structure warehouse can also be used for:



1) Industrial Buildings

2) Manufacturing Facilities

3) Warehouses

4) Construction Equipment Storage

5) Machinery Storage

6) Tool Storage

7) Warehouse Expansion

8) & More, tell us about your needs here!





6. Steel structure Warehouse Drawings & Quotation:


1) Customized design is welcomed.
2) As long as you like, we can design and provide drawings for you.
3) In order to give you an exact quotation and drawings, please let us know the length, width, eave height, and local weather. We will quote for you promptly.



Our drawings are as follows:

Large Span Multi Story Light Steel Structure Building Steel Structure Construction 1

Large Span Multi Story Light Steel Structure Building Steel Structure Construction 2



7. Loading pictures of steel warehouse building reference



The door and window will be packed safely to prevent damage. We will responsible for all missing components and wrong parts. We will provide insurance services for shipment to avoid any mistakes.



Large Span Multi Story Light Steel Structure Building Steel Structure Construction 3





8. Steel Structure warehouse materials and accessories



Large Span Multi Story Light Steel Structure Building Steel Structure Construction 4

Large Span Multi Story Light Steel Structure Building Steel Structure Construction 5





9. Steel structure building installation picture for reference

Large Span Multi Story Light Steel Structure Building Steel Structure Construction 6Large Span Multi Story Light Steel Structure Building Steel Structure Construction 7





If you are interested, I'll send you our catalog. Looking forward to having an opportunity to cooperate with you!
