Sandwich Panel Wall Structural Steel H Beam Light Steel Building Structures

Sandwich Panel Wall Structural Steel H Beam Light Steel Building Structures
Sandwich Panel Wall Structural Steel H Beam Light Steel Building Structures
Sandwich Panel Wall Structural Steel H Beam Light Steel Building Structures Sandwich Panel Wall Structural Steel H Beam Light Steel Building Structures Sandwich Panel Wall Structural Steel H Beam Light Steel Building Structures Sandwich Panel Wall Structural Steel H Beam Light Steel Building Structures Sandwich Panel Wall Structural Steel H Beam Light Steel Building Structures Sandwich Panel Wall Structural Steel H Beam Light Steel Building Structures

Large Image :  Sandwich Panel Wall Structural Steel H Beam Light Steel Building Structures

Product Details:
Place of Origin: Guangdong Foshan Lishui, China
Brand Name: TPA Housing
Certification: ISO, SGS,BV
Model Number: TPA-LSB19
Payment & Shipping Terms:
Minimum Order Quantity: 50 square meters
Price: Negotiable
Packaging Details: In bulk
Delivery Time: 5-8 work days
Payment Terms: T/T, L/C at sight
Supply Ability: 100000 square meters per month

Sandwich Panel Wall Structural Steel H Beam Light Steel Building Structures

Description
Material: Q235 Q355 Low Carbon Steel Life Span: Steel Frame About 50 Years
Installation: Installation Drawing Or Engineers Guidance Color: Customer Requirement
Roofing: Sandwich Panel. Single Steel Sheet Purlin: C.Z Shape Steel Channel
Application Fields: Steel Structural Fabrication Construction,Building,workshop Plant/warehouse/hangar

Sandwich Panel Wall Structural Steel H Beam Light Steel Building Structures



1. Steel warehouse building material parameter



Anchor bolt M20
High streng bolt M20, 10.9s
Shear nail M16
Common bolt M20
Brace M12
Tie rod Ø12
Column(Q345B) Square tube250*250*10*10 Square tube250*250*5*5
Roof beam(Q345B) HN340X250X9X14
Roof frame beam(Q345B) HN294X200X8X12
Floor main beam(Q345B) HN294X200X8X12
Floor secondary beam(Q345B) HN244X175X7X11
Staircases(Q235B) H200X200X6X8+5mm chequered plate
Stair beam(Q235B) H300X200X6X8
Roof purlin C140X60X20X3.0
Connecting plate 3~8mm
Roof tile 75mm rock wool,color sheet both sides 0.426mm
Wall panel 75mm rock wool,color sheet both sides 0.426mm
Floor deck

1.0mm

Steel door

900*2100

Aluminum windows 2000*1500
Zinc steel handrails Square tube80X40+40+30+20
Trimming 1.0mm galvanized sheet, color steel sheet





2. About steel warehouse buildings

Sandwich Panel Wall Structural Steel H Beam Light Steel Building Structures 0

TPA HOUSING steel warehouse is a light steel structure product, the main structure is cold-formed thin-wall steel component by bolt connection, one unit can achieve 30 meters in span, and it could be also combined with another unit by span each other, to achieve more than span space. Comparing with the traditional steel structure, it has the advantage of lightweight, a large span, fewer materials, low costs, saves foundations, a short construction period, safety, reliability, and attractive appearance. It is ideal for buildings both large and small.

Related Building Types: Commercial, Industrial, Manufacturing, Medical, Mini Storage, Storage Buildings





3. Why is steel used in building structures?



Steel is used because it binds well to concrete, has a similar thermal expansion coefficient, and is strong and relatively cost-effective. Reinforced concrete is also used to provide deep foundations and basements and is currently the world's primary building material.



4. Why a steel framed structure is popular?

Steel buildings are strong and durable, can last decades longer than other types of buildings, and hold their value better too. In terms of strength, they outperform other buildings significantly.





5. Basic Design Requirements: design Load: (very important)



1. Snow load:

2. Wind load:
3. Seismic magnitude:

4. Middle Column allowed or not:
5. Project location:
6. Length (sidewall, m):
7. Width (end wall, m):
8. Wall Height (eave, m):
9. Mezzanine or not? And usage:



6. What are the benefits of steel buildings?



Steel has a unique combination of properties that make it an ideal building material.

  • Steel's advantages in construction include speed, safety, optimal cost, reliability, lightweight, and design adaptability. ...
  • Quality and speed. ...
  • Strength and safety. ...
  • Economic efficiency. ...
  • Flexibility and expressiveness.




7. Steel structure building Drawings & Quotation:


1) Customized design is welcomed.
2) As long as you like, we can design and provide drawings for you.
3) In order to give you an exact quotation and drawings, please let us know the length, width, eave height, and local weather. We will quote for you promptly.



Our drawings are as follows:

Sandwich Panel Wall Structural Steel H Beam Light Steel Building Structures 1

Sandwich Panel Wall Structural Steel H Beam Light Steel Building Structures 2



8. Loading pictures of steel warehouse building reference



The door and window will be packed safely to prevent damage. We will responsible for all missing components and wrong parts. We will provide insurance services for shipment to avoid any mistakes.



Sandwich Panel Wall Structural Steel H Beam Light Steel Building Structures 3





9. Steel Structure warehouse materials and accessories



Sandwich Panel Wall Structural Steel H Beam Light Steel Building Structures 4

Sandwich Panel Wall Structural Steel H Beam Light Steel Building Structures 5





10. Steel structure building installation picture for reference

Sandwich Panel Wall Structural Steel H Beam Light Steel Building Structures 6
